LECTUS duo 3000 readers
2.2 Installation
1.
2.
–
3.
4.
5.
2.3 Important planning notes for contactless
readers
Influences on reading distance
–
–
–
–
–
Bosch Security Systems B.V.
Place the mounting frame (3) on a flat surface.
Insert the connection cable through the upper or the lower
holes of the mounting frame (3).
Note: If the connection cable comes straight out of the wall
or the cladding, you can mount the reader without the
mounting frame.
Use the screw anchors (6) and the long screws (5) to
secure the mounting frame (3).
Use the small screws (silver) (7) to attach the back plate
(2) to the mounting frame (3).
Clip the reader on the mounting frame (3) and secure it
from below with one of the two small screws (black) (8).
Metal in the "active" effective HF field.
Interference with other readers in immediate vicinity
(distance < 30 cm)
Interference by high-energy sources
Switch mode power supplies
Cable quality, shielding, and cross-section dimension
(remaining input voltage at reader, EMC)
