WINDTECH Windsos Cube 100 Mode D'emploi page 7

7
> technical specifications CUBE 125
Area --------------------------------------- 32.5m 2
Weight ------------------------------------- 1490gr
lines height -------------------------------- 750cm
Max. total weight in flight EN/LTF ----------- 125kg
Min. total weight in flight EN/LTF ----------- 70kg
Volume ------------------------------------ 3408cm 3 (24x22x11cm)
Sink rate at max. load ---------------------- 5.3m/s
> certification
WINDSOs
The CUBE has been certified according to the EN12491 standard. Therefore, it
is a guarantee for the user, both at the level of aerodynamic behavior, as at the level of
structural resistance.In these tests the opening, the stability, the rate of fall (this will
never be higher than 5.5m/s) and its structural resistance are quantified.
SPEED WARNING — NOT SUITABLE OF USE IN EXCESS OF 32m/s (If strenght test
5.3.5.1 has been passed, which is the case). In case strength test 5.3.5.2 was passed it is
not suitable for speed in excess of 49m/s. The parachute is loaded with a Dummy with
which the maximum load in flight of the set is reached. Through a protocol and the use
of a helicopter in flight at a high speed, a maximum impact is achieved, at the moment
of opening at a high speed. No breakage or sign of deterioration should show the
parachute after the whole process.
DEPLOYMENT SYSTEM WARNING — This parachute has been tested and found com-
pliant using the original manufacturer's inner container. Use of any other inner contain-
er may produce different results, including failures. The speed of opening and opening
schock test has been completed using the inner container supplied. Use of any other
inner container may produce different results (inc. failure) therefore we suggest you use
always the original inner container.
