RaidSonic Technology Icy Box IB-2227 Serie Manuel page 4

http://www.icybox.de
2bay 2.5" SATA internal enclosure
1. Model – HDD – Host Interface – Colour
Model HDD
IB-2227StS 2x 2.5" SATA
2. Package Content
1x IB-2227StS, 2x SATA Cable, 2x LED cable, 4x screw, 1x Manual, 2x keys
3. Key Features
• 2x 2.5" SATA HDD (max 9.5mm high) or SSD in 1x 3.5" bay
• Easy Swap® – tool less HDD or SSD installation and exchange
• Hard disk capacity not limited
• SATA host interface 6.0 Gbit/s
• LED for power and HDD access
• Plug & Play and Hot Swap
• Support all OS systems
4. Technical Data
Interface: 2x 15pin SATA power connector
2x 7pin SATA data connector
Material: SECC/Plastic
Dimension: 102 x 135 x 24mm
Weight: 283g
HDD height: max 9.5mm
5. Front Panel and Rear Panel
1. Key lock
2. HDD front panel
3. HDD LED indicator
2 1
Host Interface
2x SATA
1. SATA power connector (15P)
2. SATA data connector (7P)
3. Access LED connector (4P)
3
4 4
IB-2227 Series
Colour
black
1 2 3
