Wiring
IP Rating
Protection Class
Installation
Others
Dimension
Package
Net Weight
Lifetime
Note
1. "N/A"means not available.
2. Detection area is effected on volume of motion object and motion speed. The detection area is tested by a
165cm height person and walking speed is 1m/s.
4. Dimension (mm)
3. Function
On/OFF Function
Avec une lumière ambiante suffisante, la
lumière ne s'allumera pas, même si elle
est accompagnée d'un signal de
mouvement.
With sufficient ambient light, the light will
not be switched on even if with motion
signal.
5. Wiring
Add: No.17th Building, Dianda Guyuan Industrial Park, Mashantou, Matian, Guangming District, Shenzhen, China, 518106
Tel: +86 (0)755-2305 7253
*The sensor is designed for connect one load only. Connect more than one loads may damage the sensor.
6. Structure
Zone de détection : 100 %, Temps de maintien : 5 min, Capteur de lumière du jour : 25 lux
MIIDEX LIGHTING - 27 boulevard Victor Hugo, Immeuble Pythagore, 31770 Colomiers - FRANCE - www.miidex.com
Press-in Type Terminals, wire diameter:0.75-1.5mm2
IP20
Class II
Built-in
77.5*34.5*22mm
Bubble bag+Clapboard + Carton(K=A)
45±3g
CARACTÉRISTIQUES TECHNIQUES / TECHNICAL CHARACTERISTICS
5 years warranty @Ta 230V full load
PARAMETRES* :
Tension : 220-240V / AC
Fréquence : 50 / 60Hz
=Lumière ambiante : 5lux / 15lux / 50lux / disable
=Délai: 10s / 90s / 3min / 10min
=Charge évaluée : Max. 400W(inductive) 800W (resistive)
=Angle de détection : 150° (wall) 360 ° (ceiling)
=Distance de détection : 6m max
ON/OFF Sensor for Tri-proof Light
=Température de fonctionnement : -25 ~ + 60 ° C
=Energie transmise : <0.5mW
=Consommation d'énergie : < 0.5W (standby)
=Système HF : 5.8 GHz ±75 MHz, ISM Band.
Zone de détection : 0.6-1m/s
FONCTION ON/OFF / ON/OFF FUNCTION
Lorsque la lumière ambiante est insuffi-
sante, le capteur allume la lumière
lorsqu'un mouvement est détecté.
With insufficient ambient light, the sensor
switches on the light when motion is
detected.
SCHÉMA DE CONNEXION / CONNECTION-WIRE DIAGRAM
Shenzhen Merrytek Technology Co.,Ltd
Fax: +86 (0)755-2786 3012
Page 3 of 8
INITIALISATION / INITIALIZATION
RÉGLAGE USINE / FACTORY SETTING
Detection area: 100%, Hold Time: 5 min, Daylight Sensor: 25 lux
Ref : 100727-100728-100729-100730
*SPECIFICATION
Power Source
Power Frequency
Ambient Light
Time Delay
Rated Load
Detection range
Detection Distance
MC098S 2 RC
Operating temperature
Transmitted energy
Energy consumption
HF system
Detection area
Après un temps de maintien, le capteur
éteint la lumière lorsqu'aucun mouvement
n'est détecté.
After elapse of hold time, the sensor
switches off the light when no motion is
detected.
Website: www.merrytek.com
Version: A0
