SMS Casing Frame Manuel D'installation page 9

4
Select appropriate set screw
S4 (8x)
[M6x20
S4 (8x)
[M6x20
Do not tighten
S5 (8x)
OR
] [M6x10
ISO4026
S4/S5
Screw socket to
face towards holes
]
ISO4026
]
ISO4026
S5 (8x)
[M6x10
Do not tighten
SMS CASING FRAME
S4/S5
]
ISO4026
9
