Installation and Operation Manual
X-VA-1305-eng
Part Number: 541B080AAG
May, 2016

1-1 Description

1-2 Design Features

1-3 Specifications (Reference Tables 1-1 and 1-2)
®
The Brooks Model 1305 glass tube flowmeters provide a low cost means
of flow rate indication. They are designed for applications where the
metering accuracy requirements are not severe. These meters are ideal
for purge type service, seal oil systems, bearing lubrication and cooling
water indication. Model 1305 is available with vertical inlets and outlets and
standard materials of construction only.
• Capacity ranges 0.8 to 25 gpm; 3 to 50 scfm
• O-ring seal construction
• Sturdy bolted side-plate construction
• Standard NPT connections
• Vertical inlets and outlets standard
Do not operate this instrument in excess of the specifications listed
below. Failure to heed this warning can result in serious personal
injury and/or damage to the equipment.
Glass metering tubes are designed for operation up to the maximum
operating pressures and temperatures as specified herein. Due to
the inherent brittle characteristics of glass and conditions beyond
our control, tube breakage could result even within specified
operating conditions. Do not use glass tube meters with fluids that
are toxic, or chemically react with glass such as water above 140°F,
steam, alkalis, fluorine, hydrofluoric acid, or molten metal. Failure to
heed warning can result in serious personal injury and/or damage
to the equipment.

Section 1 Introduction

Model GT1305
WARNING
WARNING
1-1
