Flush Mount Installation
Please carefully follow the instructions below to properly install the microwave drawer flush to the
cabinet.
1. Prepare the cabinet opening as shown below.
Preferred electrical
outlet location
1- "
1/2
2"
22" mounting
opening width
Preferred
electrical
outlet
location
MWD2401AS Use, Care, and Installation Guide
4"
No Oven
Anti-tip
block
Front View
Installation Instructions
Anti-tip block
Floor must
Shelf Face
support
100lb
minimum
2"
NOTE: The face of
the shelf must sit
1-7/8" back from the
face of the cabinet
Cabinet Face
3/4" shelf
Side View
