DMX Values
XYExtended(10)
Channel Function
1 Dimmer
2 Fine dimmer
3 X coordinate
4 Fine X coordinate
5 Y coordinate
6 Fine Y coordinate
7 Strobe
8 Effect macros
9 Effect macro speed
10 Control
XYBasic(6)
Channel Function
1 Dimmer
2 Fine dimmer
3 X coordinate
4 Fine X coordinate
5 Y coordinate
6 Fine Y coordinate
16Ch
Channel Function
1 Red 1
2 Fine red 1
3 Green 1
4 Fine green 1
5 Blue 1
6 Fine blue 1
7 White 1
8 Fine white 1
9 Red 2
10 Fine red 2
11 Green 2
12 Fine green 2
13 Blue 2
14 Fine blue 2
15 White 2
16 Fine white 2
onAir IP Panel 1 QRG Rev. 8
QUICK REFERENCE GUIDE
Value Percent/Setting
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  010 No function
011  255 Strobe, slow to fast
000  010 No function
011  039 Color chase
040  068 Police car
069  096 Firetruck
097  125 Fire
126  154 Clouds
155  182 Fireworks
183  211 Paparazzi
212  240 Lightning
241  255 No function
000  255 Speed, slow to fast
000  255 See the Control Chart
Value Percent/Setting
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
Value Percent/Setting
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
000  255 0–100%
