Table Des Matières; Parts List - peerless-AV SR542-KAPP Instructions D'installation

Parts List

Description
A base
B caster (non locking)
C caster (locking)
D vertical column
E 3/8"-16 x 1" long bolt
F M10 split washer
G adaptor plate
H M5 x 16mm
I bracket nut bar
J shoulder washer
K column cover
L tilt head knob
M 4mm allen wrench
N spacer
O M6 x 12mm
P M4 hex nut
Q .258" x .725 x .063 washer
R 7/32" allen wrench
D ( 1 ) I ( 2 )
bracket nut bar
vertical column
M ( 1 )
4mm allen wrench
R ( 1 )
7/32" allen wrench
A ( 1 )
base
caster (non locking)
H ( 2 )
M5 x 16mm
G ( 1 )
adaptor plate
B ( 2 )
caster (locking)
F ( 4 )
M10 split washer
J ( 2 )
L ( 2 )
tilt head knob
N ( 2 )
O ( 4 )
M6 x 12mm
7
2015-06-22
Qty
1
2
2
1
4
4
1
2
2
2
1
2
1
2
4
16
4
1
C ( 2 )
3/8"-16 x 1" long bolt
K ( 1 )
shoulder
column cover
washer
P (16)
M4 hex nut
spacer
Q ( 4 )
.258" x .725 x .063
#:009-9116-2
Part #
009-2872
600-0385
600-0386
009-2876
520-1354
540-9424
009-2874
520-2161
009-2875
540-0087
009-1672
590-1109
560-9646
560-1876
520-2050
530-1055
540-2046
560-9715
E ( 4 )
washer
(2015-10-08)
