RODCRAFT RC2235 Manuel De L'opérateur page 2

Air diagram
MN2-14 (8940168574) (1/4")
8951011861 (1l)
MD2-12 (8940168576) (1/2")
MN3-14 (8940168575) (1/4")
MD3-12 (8940168577) (1/2")
6.3 bar
90 PSI
Torque
Drive
Working
Model
1
[inch] [Nm]
RC2235
1/2" 60-220
8951011796 (Ø9)
8951011784 (1/4" AG)
8951011786 (1/2" AG)
Speed Weight
Max
2 3 4
[Nm] [min-1] [kg]
300 7400 1.85
8951011791 (Ø9)
8951011836 (Ø9)
8951011831 (Ø8x5m)
8951011833 (Ø8x8m)
8951011835 (Ø8x10m)
Fig. 01
Fig. 02
Air consumtion
Dimensions
Inner Hose
Dia. L x H x W
At load
H
W
L
5 6
[inch.] [mm]
3/8" 341.5x80x58 6.8
5g
START
8951011796 (Ø9)
L
A
B
Sound-
Air Inlet Pressure
Average
7 8
[Nl/s] [inch] [dB(A)]
1.7 1/4''
5g
R
F
Rev. max Fwd min Fwd max
Fwd. / Rev
30 to 50 cm hose
8951011836
H
Vibrations
Sound-
Power
L L
ahd k
pA wA
9 10 11
[dB(A)] [m/s²] [m/s²]
97 108 43.5 4.8
