PREPARATION FOR USE
CONNECTIONS
Cables used here are available on the market.
[ANTENNA CONNECTION]
VHF/UHF
RF Cable
OR
VHF
UHF
Flat twin-
VHF/UHF
lead cable
Combiner
You can bracket this product as wall mounting TV using the arm adapted for 100mm (commer-
cially available).
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO
WIDE SLOT, FULLY INSERT.
Note:
•
For your safety and to avoid damages to the unit, unplug the antenna cable from the
ANT jack before moving the unit.
[EXTERNAL CONNECTION]
VIDEO1 input
(OUT)
ex.
Audio Cable
(OUT)
Video Cable
Video Cassette
OR
(OUT)
Recorder
S-Video Cable
Notes:
The AUDIO L jack is for mono input. The sound is heard from both speakers. Use this jack for
●
connecting monaural audio equipment.
The S-VIDEO jack is given priority over the VIDEO jack.
●
VIDEO2 input
ex.
(OUT)
Audio Cable
Video Camera
(OUT)
Component
Video Game
Video Cable
Note:
The TV can only accept a 480i (interlaced) video signal.
●
SELECTING AUDIO/VIDEO INPUT
When you use the AUDIO/VIDEO input jacks, select "VIDEO1" or "VIDEO2" mode by hit-
ting [INPUT SELECT] on the remote control. The input mode changes by hitting the button
as following:
INPUT
TV channel
SELECT
All manuals and user guides at all-guides.com
[CATV/SATELLITE CONNECTION]
*
CATV Box
or Satellite Box
OUT
IN
75-ohm
Coaxial Cable
OR
RF Cable
*
Some cable TV systems use scrambled signals and
require a special converter to receive these channels.
Consult your local cable company.
Rear of this TV
(IN)
(IN)
(IN)
(IN)
Rear of this TV
(IN)
VIDEO1
VIDEO2
INSTALLING THE BATTERIES
1
2
[BATTERY PRECAUTIONS]
• Be sure to follow the correct polarity as indicated in the battery compartment.
Reversed batteries may cause damage to the device.
• Do not mix different types of batteries together (e.g. Alkaline and Carbon-Zinc) or old batteries
with fresh ones.
• If the device is not to be used for a long period of time, remove the batteries to prevent
From Cable
damage or injury from possible battery leakage.
System
• Do not try to recharge batteries not intended to be recharged; they can overheat and rupture.
or Satellite
Antenna
PHOTO STAND
From Cable
System
Photo Stand
Adjust the length of the stand in 5 levels to
change the angle of the TV.
OPERATIONS
REMOTE CONTROL AND FRONT PANEL FUNCTION
POWER button
To turn TV on/off
VOL(UME)
X X
/
Y Y
To adjust volume
MENU button
To view on-screen menu
MUTE button
To mute sound
DISPLAY button
To display CH No./Audio Status
POWER
MENU
Y VOLUME X
L CHANNEL K
SELECT
MENU
Y VOLUME X
Infrared Sensor Window
Note:
If some digits appear in the corner of the screen when the unit is turned on for the first time, hit
●
[POWER] without unplugging the power cord.
Install two AAA batteries (supplied)
3
matching the polarity indicated inside
battery compartment of the remote con-
trol.
INPUT
SELECT
INPUT SELECT button
To select TV or external input
POWER
o
CH
buttons
m
p
CH(ANNEL)
VOL
n
1
2
3
Channel number buttons
4
5
6
To select channels
7
8
9
MENU
0
+100
SLEEP button
MUTE
SLEEP
CH RET
DISPLAY
CH(ANNEL) RET(URN) button
To return previous screen
POWER
L CHANNEL K
SELECT
POWER button
To turn TV on/off
SELECT button
K K
L L
CHANNEL
/
To select channels
VOLUME
X X
/
Y Y
buttons
To adjust volume
MENU button
To view on-screen menu
K K
L L
/
buttons
buttons
