BAYLED SURGE LINEAR Instructions De Montage page 2

30W - 80W VERSIONS
1
2
DIMENSIONS
160
Power Total Height (H)
30W / 40W 3000mm
40W / 60W / 80W 3500mm
40W / 60W / 80W 4000mm
40W / 60W / 80W 4500mm
60W / 80W 5500mm
350
3
4
1
Head (H1)
365mm
500mm
500mm
2
500mm
500mm
6
Nut
Washer
Flange
Anchor Bold
Concrete
7
1
8
POWER ON
SURGE LINEAR INSTALLATION INSTRUCTION
5
220V AC
ELECTRICITY
LINE
Pole
Electrical Conduit
Cable
2
Power factor > 90% full load
N
BLUE (Neautral)
YELLOW / GREEN
(Ground)
L
BROWN (Live)
-25°C / +55°C
OPERATION TEMPERATURE
