OPERATING PROCEDURES
4. Place the nozzle over the valve stem of the tire and fold down the lever so it is
. Turn the compressor on/off switch (I, fig.1) to the "ON" position (depress the
6. Monitor the air compressor pressure gauge (M, fig.1) while inflating.
7. When desired pressure has been reached, turn compressor off (depress the
8. Flip the nozzle lever back into the up position and disconnect the hose.
9. For inflating other articles, select the appropriate inflator nozzle (V, W, X; fig.2)
10. Inflate the object as above.
NOTE: For athletic balls, moisten needle before inserting it into the ball's valve.
CAUTION: Allow the air compressor to cool down approximately 5 minutes be-
!
WORK LIGHT
The twin work lights (F, fig.1) are switched by the work light on/off switch
(K, fig.1) located at the top of the front panel.
1. Turn on the master power switch (L, fig.1) (depress the side of the switch
2. Move the work light on/off switch (K, fig.1) to the "on" position (depress the
MAINTENANCE
WARNING!
= Do not open the Jumpstart. There are no user-serviceable parts in this unit.
= Do not use the air compressor as a breathing device
!
= Do not allow compressed air near the body. Introducing pressurized air into
FUSE REPLACEMENT
1. The 15 amp main unit fuse (B, fig.1) is an ATC-15 or equivalent
2. To check the fuse, pull it from its socket in the control panel.
3. Check the filament between the two blades.
4. If it is melted,
. Make sure master power switch (H, fig.1) is off (the side of the switch marked
6. Replace the fuse with an identical fast-acting 15 amp ATC-15 or equivalent blue
!
CAUTION: Never replace a fuse with one that has a higher amperage rating.
DISPOSAL
The IJS2000 contains a SEALED, non-spill able LEAD-ACID BATTERY. It MUST
BE disposed of properly. Contact local recycling authorities for information on
disposal according to local laws.
Risk of explosion: DO NOT INCINERATE.
parallel with the hose to lock the nozzle into position.
side of the switch marked "I").
side of the switch marked "O") with the compressor on/off switch (I, fig.1)
and insert it into the hose nozzle. Fold the lever down to lock the adaptor in
place.
For other pneumatic articles, the nozzle should be inserted into the valve and
held tightly to insure a good seal.
tween inflation of each car tire. Whether filling large-volume items like tires or
other inflatables, the compressor should not be run continuously for more than
10 minutes; after which it should be allowed to cool for 5 minutes. Over-use
could cause over-heating and motor failure.
marked "I").
side of the switch marked "I").
open orifices, through skin, or open wounds could cause death.
blue automotive blade-type fuse.
"O" is depressed).
automotive blade-type fuse.
9
