1

Properties I Technical data

1.1

Properties

Figure 686 01 l 686 05
Parts having contact with fluid are made of gunmetal and stainless steel as well as for drinking
water approved elastomers and plastics
Removable `Top Entry` interior bonnet
KHS-PLUS maximum flow isolating ball valve DIN-/DVGW approved according to DIN EN 13828, W 570
Pressure-impact free operation, transit time for 90°, open 90 sec, closed 15 sec.
Pressure stage PN 16
Free from dead spots
2-point control
With position feedback (24 V DC)
Drive can be positioned on the valve in 45° steps
Manual operation possible
Valve closes during power failures
1.2

Technical data

Description
Torque
Hold torque
Transit time for 90°
Voltage
Power consumption during actuation
Power consumption during standstill
Rotate angle
Permissible ambient temperature
Permissible ambient humidity
Protection class
Operating noise
Drive weight
Feedback
Connection cable
Figure 686 01
Open 90 sec. I Closed 15 sec.
24 V (+/- 20 %) (DC)
3,5 W / 5 VA
2,5 W
< 85 % relative humidity without condensation
1,3 kg
Position feedback 0...10 V
0,9 m, 4 x 0,75 mm²
© www.kemper-group.com – 01.2024 / K410068601001-00 – 15 /60
Figure 686 05
7 Nm
7 Nm
230 V~ (+/- 10 %) (AC), 50 Hz
4,5 W / 7 VA
3,5 W
90°
Up to 55 °C
IP54
< 30 dB(A)
1,2 kg
1,2 m, 2 x 0,75 mm²
