Connection Instructions
POWER
VIDEO
Camera
Supplied Power Cord
Angles
2
1
Note:
• When adjusting the screen tilt, please make sure not to damage the screen.
• After adjusting the tilt, check the cables to ensure the monitor is not pulled over.
5 English
Amprifier, etc.
Amprifier, etc.
AUDIO OUT
IN IN IN
OUT OUT
VIDEO A VIDEO B S-VIDEO
OUT
VIDEO IN
Camera
Recorder or
External Monitor
(Lift)
100 (3.9)
165˚
(Swivel)
• When connecting, ensure the power supply to each
unit is switched off.
• The other devices and connection cables required
are sold separately.
S-VIDEO OUT
Recorder, etc.
S-VIDOE IN
VGA
OUT
Supplied VGA Signal Cable
video recorder
or PC, etc.
(Tilt)
165˚
