Mounting
• Wall Mount: See below.
• Rotating Stand: See Rotating Stand Assembly Instructions.
#8 x 1" (4)
All manuals and user guides at all-guides.com
2"
50.8mm
7.5"
190.5mm
©
2016 The Vollrath Company L.L.C.
Instruction Sheet
Spring Loaded Cup Dispenser
Accommodates Cups with
Item No. Rim Diameter
SLC-1 2¹⁄₄ - 2⁷⁄₈" (5.7 - 7.3 cm)
SLC-2 2⁷⁄₈ - 3¹⁄₂" (7.3 - 8.9 cm)
SLC-3 3¹⁄₂ - 4¹⁄₈" (8.9 - 10.5 cm)
SLC-4 4¹⁄₈ - 47⁄₈" (10.5 - 12.4 cm)
Wall Mounting Instructions
1. Drill the mounting holes for the brackets.
2. Install the mounting screws into the brackets.
3. Align the brackets on the dispenser with the
wall-mounted brackets.
4. Slide the dispenser onto the wall-mounted
brackets.
Part No. 350499-1 ml 8/24/16
