ODB 4
4.
INSTALLATION DU CÂBLE PRINCIPAL
MAIN CABLE INSTALLATION
Passer dans le joint
Route through the seal
Préparer le câble
Porteur (le cas échéant)
Mèches aramides
Micromodules
Prepare the cable
Strength member (if any)
Aramid yarns
Bundles
50 mm
55 mm
1500 mm
Câble avec porteur
Câble sans porteur
Cable with strength member
Cable without strength member
Arrimer
Clamp
x 1
x 2
Bloquer le porteur sous la vis
Fasten the strength member
under the screw
ABS1552/B
9/16
