Abit Guru CLOCK Mode D'emploi page 10

(2) To add or delete your friend-list into the five
preset calling numbers for the "Private Call"
function, left-click
selected from the "Friends" column.
(3) To add or delete your friend-list into the five
preset calling numbers for the "Conference
Call" function, first select the Group ID, and
then left-click
group members from the "Friends" column.
Click <Apply> to save this page.
Click <OK> to save and leave this page.
Click <Cancel> to cancel setting and leave this
page.
6. To do the Guru Clock monitor setting, pull down
the scroll bar to locate the Guru Clock icon and
left-click on it.
(1) There are [Fan], [Voltage], [Frequency], and
[Temperature] monitoring items available to
select. Check the box for the item you want to
monitor through Guru Clock.
(2) [Time Format]: Select the 12-hour or 24-hour
format for your present time.
(3) [Temperature Format]: Select the
temperature-measuring unit in Celsius or
Fahrenheit. The value of measuring unit on the
LCD screen will be replaced in real time.
Click <Apply> to save this page.
Click <OK> to save and leave this page.
Click <Cancel> to cancel setting and leave this
page.
10
All manuals and user guides at all-guides.com
or button after
or button after selected
Guru Clock
