STYLE No: 64015
THIS PRODUCT IS NOT INTENDED FOR INSTITUTIONAL OR COMMERCIAL USE.
If you have any questions or missing parts, contact us. DO NOT return product parts to the store
from where it was purchased before contacting Delta Children's Products Customer Service.
Make sure that all preassemble parts are tight. The appearance of your product may be different
from that pictured in this booklet.
To register your product for important safety alerts and updates to your product
please visit http://deltaenterprise.com/register.asp
DECEMBER 9, 2010, 64015-R3
All manuals and user guides at all-guides.com
READ ALL INSTRUCTIONS BEFORE
ASSEMBLY AND USE.
KEEP INSTRUCTIONS FOR FUTURE USE.
ADULT ASSEMBLY REQUIRED
DUE TO THE PRESENCE OF SMALL PARTS
DURING ASSEMBLY, KEEP OUT OF REACH OF
CHILDREN UNTIL ASSEMBLY IS COMPLETE.
Customer Service:
Web Site: www.deltachildrensproducts.com
Delta Children's Products
114 West 26th Street
New York, NY 10001
Tele.212-645-9033
COLOR
Conforms to
ASTM F1169 & F1821
Safety Standards
A
REV
FTY
.
©2010 DELTA ENTERPRISE CORP.
Publicité
Sommaire des Matières pour Delta 64015
- Page 1 If you have any questions or missing parts, contact us. DO NOT return product parts to the store from where it was purchased before contacting Delta Children’s Products Customer Service. Make sure that all preassemble parts are tight. The appearance of your product may be different from that pictured in this booklet.
- Page 2 Ne pas utiliser le lit de bébé si toute pièce manque, est endommagée ou brisée. S’adresser à Delta Children's the mattress support and the mattress to the next highest position.
- Page 3 - Do not scratch or chip the finish. -TOUJOURS SURVEILLER L’ACTIVITE DE VOTRE ENFANT LORS QU’IL SE TROUVE DANS SA CHAMBRE. - Inspect the product periodically, contact delta children's products for replacement parts or questions. REMARQUES SUR LE SOIN ET L’ENTRETIEN : - Do not store the product or any parts in extreme temperatures and conditions such as a hot attic or a -NE PAS RAYER OU EBRECHER LA FINITION.
- Page 4 All manuals and user guides at all-guides.com PARTS: MAKE SURE THAT ALL PRE-ASSEMBLED PARTS ARE TIGHT. C. RIGHT REAR LEG x 1 PART # 21470 A. BACK RAIL x 1 PART # 21465 E. RIGHT FRONT LEG x 1 PART # 21472 BACK INSIDE BOTTOM LABEL B.
- Page 5 All manuals and user guides at all-guides.com PARTS: HARDWARE KIT IS PART # 21475 FOR COLOR 145 OR #21476 FOR COLOR 205. SEE FRONT COVER. L. M6 x 85 mm BOLT x 6 Flat Head Screwdriver (not supplied) M. M6 x 60 mm BOLT x 4 N.
- Page 6 All manuals and user guides at all-guides.com SECTION 1: CRIB ASSEMBLY STEP 1 PARTS AND TOOLS REQUIRED TO COMPLETE STEP C. RIGHT REAR LEG x 1 A. BACK RAIL x 1 R. BARREL NUT x 4 M4 ALLEN WRENCH SUPPLIED S.
- Page 7 All manuals and user guides at all-guides.com SECTION 1: CRIB ASSEMBLY STEP 2 PARTS AND TOOLS REQUIRED TO COMPLETE STEP N. M6 x 40 mm BOLT x 6 PRODUCT LABEL LEFT INSIDE BOTTOM WARNING LABEL LABEL H. RIGHT CRIB END x 1 M4 ALLEN WRENCH FROM STEP 1 G.
- Page 8 All manuals and user guides at all-guides.com SECTION 1: CRIB ASSEMBLY STEP 3 PARTS AND TOOLS REQUIRED TO COMPLETE STEP M4 ALLEN WRENCH SUPPLIED K. MATTRESS SUPPORT x 1 P. M6 x15 mm BOLT x 4 FROM STEP 2 ATTACH THE MATTRESS SUPPORT (PART K) IN ALL CORNERS USING (1) M6x15 mm BOLT (PART P) IN EACH CORNER.
- Page 9 All manuals and user guides at all-guides.com SECTION 1: CRIB ASSEMBLY STEP 4 PARTS AND TOOLS REQUIRED TO COMPLETE STEP E. RIGHT FRONT LEG x 1 F. FRONT RAIL x 1 S. Φ4x30 mm METAL PIN x 2 M4 ALLEN WRENCH SUPPLIED M.
- Page 10 All manuals and user guides at all-guides.com SECTION 1: CRIB ASSEMBLY STEP 5 PARTS AND TOOLS REQUIRED TO COMPLETE STEP N. M6 x 40 mm BOLT x 6 FROM STEP 4 M4 ALLEN WRENCH FROM STEP 3 SUPPLIED ATTACH THE ASSEMBLY FROM STEP 4 TO THE ASSEMBLY FROM STEP 3 USING (6) M6x40 mm BOLTS (PART N).
- Page 11 If you have any questions or missing parts, contact us. DO NOT return product parts to the store from where it was purchased before contacting Delta Children’s Products Customer Service. Make sure that all preassemble parts are tight. The appearance of your product may be different from that pictured in this booklet.
- Page 12 All manuals and user guides at all-guides.com SECTION 2: TODDLER BED CONVERSION STEP 1 PARTS AND TOOLS REQUIRED TO COMPLETE STEP M4 ALLEN WRENCH SUPPLIED FINISHED CRIB REMOVE THE FRONT RAIL INSTALLED IN STEP 4 OF SECTION 1 CRIB ASSEMBLY.
- Page 13 All manuals and user guides at all-guides.com SECTION 2: TODDLER BED CONVERSION STEP 2 PARTS AND TOOLS REQUIRED TO COMPLETE STEP J. STABILIZER BAR x 1 R. BARREL NUT x 2 S. Φ4x30 mm METAL PIN x 2 M4 ALLEN WRENCH SUPPLIED FROM STEP 1 L.
- Page 14 STABILIZER BAR MUST BE USED WHEN CONVERTED TO A TODDLER BED. A TODDLER BED GUARDRAIL IS AVAILABLE FOR THIS CRIB. PLEASE SEE YOUR CRIB RETAILER, VISIT WWW.DELTACHILDRENSPRODUCTS.COM OR CONTACT DELTA CONSUMER CARE FOR MORE INFORMATION. THIS CRIB USES DELTA STYLE # 0080 GUARDRAIL.
- Page 15 All manuals and user guides at all-guides.com SECTION 3: FULL SIZE BED CONVERSION STEP 1 PARTS AND TOOLS REQUIRED TO COMPLETE STEP M4 ALLEN WRENCH SUPPLIED YOU HAVE THE OPTION TO CONVERT THE CRIB TO A FULL SIZE BED. SIMPLY FOLLOW STEPS IN REVERSE ORDER TO DISASSEMBLE THE CRIB.
- Page 16 (FROM SECTION 3 STEP 1) USING (8) M6x15mm BOLTS (PART P). FOLLOW ALL INSTRUCTIONS SUPPLIED WITH THE BEDFRAME. NOTE: BED FRAME SYSTEM IS NOT INCLUDED, SEE YOUR FURNITURE OR MATTRESS RETAILER. CONTACT DELTA CHILDREN'S PRODUCTS FOR INFORMATION OR WITH QUESTIONS.
- Page 17 Delta. To register your product for important safety alerts and updates to your product please visit http://deltaenterprise.com/register.asp...
