Daewoo Dhome DA7KWE Mode D'emploi page 7

2. Place the appliance on a horizontal flat surface.
3. Keep minimum (50 mm) space around the appliance for optimal ventilation.
4. Do not place the appliance near a heat source. This could damage the appliance.
5. Do not expose the appliance to direct sunlight.
6. Do not install the appliance where it could be subjected to:
- Mechanical vibration or shock
- Excessive dust
- Lack of ventilation, such as cabinet or bookcase
7. Make sure the air inlet and outlet are not blocked, or close to loose objects e.g. curtains.
If the appliance is tipped more than 45°, let the appliance stand in an upright position for
5
24 hours before use.
5.2 Connecting the exhaust hose
See image 2.
1 Do not extend the exhaust hose with another hose.
1. Connect the hose connector to the exhaust hose.
Make sure to fully extend the exhaust hose.
5
2. Connect the window kit adapter to the other end of the exhaust hose.
3. Extend the window kit to fit the window opening.
4. Lock the window kit between the window and the window frame.
5. Connect the window kit adapter to the window kit.
6. Connect the hose connector to the air exhaust of the appliance.
6 OPERATION
1. Press the power button to switch on the appliance.
The appliance switches on after 3 seconds.
5
2. Press the mode button to select the desired operation mode. The different modes are:
- Cool: air circulation and cooling
- Dry: low air circulation and dehumidifying
- Fan: air circulation without cooling
3. Repeatedly press the speed button to select the desired speed.
4. Use the arrow buttons to set the desired temperature.
5. Press the power button to switch off the appliance.
The appliance switches off after 10 seconds.
5
6.1 Sleep mode (remote control)
The sleep mode can only be activated in cool mode.
5
1. Press the sleep button on the remote control. Every hour the temperature increases by
1°C.
7
