Rotate the counterweight counter clockwise (seen from the front) to adjust the down force
according to the cartridge manufacturer's recommendations. One mark on the scale
represents 0.05g of down force.
NOTE: The recommended down force for the factory fitted cartridge is 3.5±0.5g.
Anti-Skate Adjustment
• A small outward "anti-skating" force can be applied to the tone arm to compensate for the
"skating" force that pulls the arm toward the center of the record.
• For best performance during normal turntable usage, it is recommended to set the
anti-skate control knob to the same value as indicated by the downforce scale
dial.
Stereo System Connection
RCA Jacks
· The RCA Jacks of this unit are shared as both the Phone output jacks and the Line
output jacks. They are determined by the Phono/Line Switch.
· When used as a line output, the jacks output analog line-level signals and could be
connected directly with a pair of active speakers or the appropriate input of your stereo
system. When used as a Phono output, they should be connected to the phono
pre-amplifier or the phono input of the stereo system.
· The Red plug connects with the Right channel and the White plug connects with the Left
channel.
Note:
· If the Phono/Line switch is set at LINE position but RCA jacks connected to the stereo
system's phono input, the sound might be distorted due to input overload and could
damage your stereo system.
· If the Phono/Line switch is set at PHONO position but RCA jacks connected to the stereo
system's line input, the volume will be very low due to lacking signal pre-amplification.
RCA Jack is not designed to be connected directly to the passive/unpowered speakers
and if it does, the volume will be very low.
EN - 17 -
