Installer manual
4. Description of the components
4. 1 . Smoke generator
4.2. Electronic circuit and smoke container
1
5
4
Description of the components
Power connector
2
6
3
1
2
3
4
5
6
7
7
NI-UN
Tamper
Générateur de fumée connection
cable
Piezoelectric siren
Jumper Led (inserted Led enabled)
Reset button
Programming Dip-Switch
Wiring terminal board
