Silent Call Communications Medallion Serie Instructions D'installation Et D'utilisation

INSTALLATION:
1. Remove your Silent Call Medallion Series wireless doorbell transmitter from its packaging.
2. Place the doorbell transmitter firmly against the wood frame on the outside door trim, approximately 48 inches up from the
doorsill. Note that if the doorbell transmitter is mounted to a metal surface, the range will be greatly reduced.
3. Using a pencil, mark each screw hole on the mounting surface. Remove the doorbell transmitter from the wood trim.
4. Using a small nail or other sharp pointed object, make a starter hole for transmitter case screws (included).
5. Screw transmitter to door trim making sure printing on the case is right side up.
6.
To test operation of transmitter, press doorbell button. This will cause your Silent Call Medallion Series receiver to operate
OPERATION:
1. Whenever the doorbell transmitter button is pressed, a coded wireless signal is sent to any Silent Call Medallion
receiver programmed to learn the transmitter, causing it to activate.
2. Transmission range using a Silent Call Medallion Series receiver is about 500 feet.
Transmitter Settings
The Silent Call Medallion system is digitally encoded. All Silent Call Medallion Series receivers are capable of receiving one
million different codes and the transmitters are preset at the factory to send one of the million different codes. Please refer to
your receiver manual for instruction on teaching the transmitter code to the receiver.
Replacement Batteries:
Use one 12V 23AE Alkaline Batteries. 23AE Battery may be purchased from local retail stores. Transmitter is shipped with 1
GP Alkaline Battery Type 23AE. Batteries may be purchased Online at
Changing Battery:
1. Remove doorbell transmitter from doorframe and slide battery cover off, exposing battery.
2. Remove battery and install new 23AE, 12 volt alkaline battery.
3.
Make sure polarity (+ & -) is correct when installing new battery.
REGULATORY INFORMATION NOTICE:
Unauthorized changes or modifications could void the user's authority
to operate the equipment.
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation of
the device. This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver
• Connect the equipment into an outlet on a circuit different from that
to which thereceiver is connected.
• Consult the dealer or an experienced radio/television technician for help
Technical Support
For technical support on this or any other Silent Call product, please feel free to contact us. You can reach us by phone at
800-572-5227 (voice or TTY) or by Email at
Installation and Operating Instructions
Model DB4-MC
Wireless Doorbell Transmitter 418MHz
support@silentcall.com
www.silentcall.com
Document# 109107
.
