PCIe Slot Configurations (For CPU with 28 PCIe lanes)
Single Graphics Card
Two Graphics Cards in
CrossFireX
TM
or SLI
Mode
Three Graphics Cards in
TM
3-Way CrossFireX
Mode
TM
or 3-Way SLI
Mode
For a better thermal environment, please connect a chassis fan to the motherboard's chas-
sis fan connector (CHA_FAN1, CHA_FAN2 or CHA_FAN3) when using multiple graphics
cards.
PCIE1
PCIE2
N/A
x16
TM
N/A
x16
N/A
x8
PCIE3
PCIE4
PCIE5
N/A
N/A
N/A
N/A
N/A
x8
N/A
x8
x8
X99 Taichi
