NOTE Peel protective covering from backboard before assembly.
:
STEP 1
Insert the three Bolts H1 through Back plate P2, Backboard P1, Rim Assembly P3
and the three Nuts H2. Fasten with T1 Wrench until Rim is Secure but DO NOT
over tighten.
STEP 2
Attach Net P4 to Rim Assembly P3. Loop net over metal loop and tuck under as
shown in Detail 1 and Detail 2.
DETAIL 1
(RIM ASSEMBLY)
P3
P4
All Rights Reserved
©
2
0
13
E
c s
a
a l
d
e
S
DETAIL 2
p
r o
s t
P1
H2
3
P2
H1
