Sensor Installation
The LEDVANCE FLAT PANEL offers a Plug & Play Motion Sensor that is sold separately.
1.
The luminaires are shipped with a
plate that covers the sensor hole.
There is a flexible flat cable with
terminals secured to the back of
the plate. The contacts of the
terminals correspond to the wires
of the sensor. Remove the plate
before or after you install the
fixture in the ceiling.
Sensor Wiring Diagram
5-YEAR LIMITED WARRANTY
LEDVANCE warrants the Product to be free from defects in materials and workmanship from date of purchase for
the specified warranty period when used as directed. Failure to comply with Product warnings and instructions
shall void the warranty. This warranty does not cover Product subject to accident, neglect, abuse, misuse, or acts
of God. If Product fails to operate according to the warranty, return Product to place of purchase with proof of
purchase date and LEDVANCE will replace with the same or similar Product free. For additional information,
contact 1-800 LIGHTBULB (1-800-544-4828); Email: lightbulb@ledvance.com. THIS IS THE EXCLUSIVE REMEDY
AVAILABLE. LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES IS EXPRESSLY EXCLUDED. SOME STATES
AND JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE OR
PROVINCE.
4114511
2.
Remove the flat cables that were
secured to the back of the plate
and insert the connectors
approved sensor.
3.
Install the sensor by snapping it
into the slot. Ensure it is securely
to an
fixed.
in
