No. Description
1
ATX 12V Power Connector (ATX12V3)
2
ATX 12V Power Connector (ATX12V1)
3
CPU Fan Connector (CPU_FAN1)
4
CPU Fan Connector (CPU_FAN2)
5
2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
6
2 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2)
TM
7
V-Probe
8
ATX Power Connector (ATXPWR1)
9
USB 3.0 Header (USB3_6_7)
10
SATA3 Connector (SATA3_A1)
11
SATA3 Connector (SATA3_A2)
12
SATA3 Connector (SATA3_0)
13
SATA3 Connector (SATA3_3)
14
SATA3 Connector (SATA3_1)
15
SATA3 Connector (SATA3_4)
16
SATA3 Connector (SATA3_2)
17
SATA3 Connector (SATA3_5)
18
SATA Express Connector (SATAE_1)
19
Slow Mode Switch (SLOWMODE)
20
BIOS Selection Switch (BIOS_SEL1)
21
System Panel Header (PANEL1)
22
Chassis Speaker Header (SPEAKER1)
23
Post Status Checker (PSC)
24
Power Switch (PWR)
25
Reset Switch (RST)
26
Power LED Header (PLED1)
27
Rapid OC Button (+) (PLUS)
28
Rapid OC Button (–) (MINUS)
29
HDD Saver Connector (SATA_PWR_1)
30
Menu Button (MENU)
31
LN2 Mode Switch (LN2MODE)
32
Chassis Fan Connector (CHA_FAN2)
33
PCIe ON/OFF Switch (PCIE_SWITCH)
2
(VOL_CON1, VOL_CON2)
