5. Swing the bucket support frame up and attach the front
of the tube to the 2 side frame pieces. Insert the tube
by depressing the brass push pin and pushing until it is
securely in place. When secure in place, the brass push pin
will extend out of the locking hole. An audible click will be
heard. Repeat this step for other side (Fig C).
C
6. Attach backrest by depressing brass push pins and sliding
either end into the receptacles located on the backside of
the frame. Ensure brass push pins fully protrude out of the
locking hole. An audible click will be heard once locked.
7. Place the commode pail between the pail brackets on the
commode frame (Fig D).
8. Press the commode seat and lid on to the back tube of the
bucket support frame. Commode seat
before use. Ensure the bucket lies flat on the frame.
Remove the bucket lid before use. (Fig E).
D
ADJUST COMMODE HEIGHT
1. Depress the height adjustment button and slide the lower
leg upward or downward until the height adjustment
button is fully engaged in the desired hole. An audible click
will be heard.
2. Repeat for other three leg attachments.
3. To ensure legs are locked into place, pull gently on
each leg.
CAUTION:
Ensure that all four commode legs are adjusted to
the same height, and that all height adjustment buttons
protrude fully through adjustment holes before use.
4
Side
Frame
Support Frame
Backrest
Bucket
E
MUST
be installed
