IMPORTANT SAFETY INFORMATION
Operating temperature: -40°C to +40°C (-40°F to 104°F).
Suitable for use in wet locations.
All wiring and connectors used with this equipment shall be rated a minimum of 90°C (194°F)
Installation Instructions – Surface Mounting
1: Disconnect power from the luminaire and follow proper lockout/tagout procedures before beginning installation or maintenance.
2: Remove the existing luminaire (if present) and dispose of per local requirements.
3: Remove both (2) clear knockouts from sides of fixture to gain access to dip switches. Dip switches are used to change wattage, color temperature
and enable/disable photocell.
4: Adjust dip switches position for desired settings. (Figure 1)
5: Reinstall clear knockouts from Step 3.
6: Remove quick mounting plate from back of fixture. (Figure 2)
6a. Remove single screw on the side.
6b. Pull plate and lift.
6c. Remove plate from fixture hanging ring.
7: Mount quick mount plate to junction box or desired surface. Use plate as a template. (Figure 3)
8: Hang fixture on quick mounting plate by utilizing the hanging ring. (Figure 4)
9: Connect the supply wires to junction box, or similar, as shown in wiring diagram below.
NOTE: The correct polarity of the dimming connections is essential to proper operation.
NOTE: If not using the dimming functionality, insulate the Dim(+) (purple) and Dim(-) (pink) wires separately (bare wires should not be left
exposed). DO NOT connect the Driver Dim(+) (purple) to the Driver Dim(-) (pink) wire as the fixture will not operate correctly.
10: Swing fixture up flush with quick mounting plate. (Figure 5)
11: Reinstall screw that was removed in Step 6.
12: Power can now be restored to the system.
Installation Instructions – Pendant Mounting
1: Disconnect power from the luminaire and follow proper lockout/tagout procedures before beginning installation or maintenance.
2: Remove the existing luminaire (if present) and dispose of per local requirements.
3: Remove both (2) clear knockouts from sides of fixture to gain access to dip switches. Dip switches are used to change wattage, color temperature
and enable/disable photocell.
4: Adjust dip switches position for desired settings. (Figure 1)
5: Reinstall clear knockout from Step 3.
6: Run wires through ¾" conduit to fixture. (Figure 6)
7: Connect the supply wires as shown in the wiring diagram below.
NOTE: The correct polarity of the dimming connections is essential to proper operation.
NOTE: If not using the dimming functionality, insulate the Dim(+) (purple) and Dim(-) (pink) wires separately (bare wires should not be left
exposed). DO NOT connect the Driver Dim(+) (purple) to the Driver Dim(-) (pink) wire as the fixture will not operate correctly
8: Screw fixture onto ¾" conduit. (Fixture 6)
9: Power can now be restored to the system.
