Product Characteristics
RADIO SPECIFICATION: Frequency 2402 MHz ~ 2480 MHz; Transmit power 1 mW or less
OPERATING ENVIRONMENT: Operating temperature from –20 °C to 55 °C
STORAGE ENVIRONMENT: Storage temperature from –40 °C to 70 °C
RELATIVE HUMIDITY (R.H.): Relative humidity up to 95% at 40 °C (non-condensing)
POWER CONSUMPTION: Maximum 130 mVA for two 1.5 V AAA batteries
BATTERY TYPE: Alkaline 24 A (ANSI/NEDA) and LR03 (IEC), or Zinc Chloride 24 D (ANSI/NEDA)
and R03 (IEC).
DIMENSION (W × L × H): 39.0 mm × 71.0 mm × 37.0 mm
WEIGHT: 60 g with battery
WARRANTY: Three months (Does not cover normal wear and tear of mechanical parts and batteries)
BLUETOOTH: Bluetooth Version 2.1 + EDR compliant, SPP profile, Class 2 device
SAFETY: The U1177A complies with the requirements of the following safety and regulatory
standards:
• FCC Part15C (Certification) (15.209, 15.247)
• FCC Part15B (15.109)
• FCC ID: 2ACWAU1177A
• RSS-210 Issue 8:2010 IC: 6310A–U1177A
• ICES–003 Issue 4:2004
• EN 300 328 V1.7.1
• EN 301 489–1:V1.9.2/EN 301 489–17:V2.2.1
• EN 55022:2010/EN 55024:2010
• RF (HEALTH)–EN 62311:2008/RF (Bluetooth)–EN 300 328 V1.7.1
• EN 60950–1:2006+A11:2009+A1:2010+A12:2011
• India Equipment Type Approval (ETA) Certificate No: NER-ETA/920
• COFETEL Certificate No: RCPAGU111-1066, registered under Keysight Technologies
Mexico S de RL de CV
"This telecommunication equipment conforms to the NTC technical requirement"
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy; and if not
installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
•
•
•
•
The term "IC" before the radio certification number only signifies that the device meets
industry Canada technical specifications.
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected
Consult the dealer or an experienced radio/TV technician for help
2
Complies with
IMDA Standards
(N5465-19)
