INSTALLATION INSTRUCTIONS
Universal Low Profile Swingout Arm for 37" to 63" Flat Panels
1321 S. State College Blvd.
Fullerton, CA 92831 USA
Phone: (001)-714-632-7100
AM175
NORTH AMERICA
USA and Canada
Phone: 800-368-9700
Fax: 800-832-4888
Other Locations
Fax: (001)-714-632-1044
9531-008-001-0X Rev.B
Publicité
Table des Matières
Manuels Connexes pour Premier Mounts AM175
Sommaire des Matières pour Premier Mounts AM175
- Page 1 INSTALLATION INSTRUCTIONS AM175 Universal Low Profile Swingout Arm for 37” to 63” Flat Panels NORTH AMERICA 1321 S. State College Blvd. Fullerton, CA 92831 USA USA and Canada Phone: 800-368-9700 Fax: 800-832-4888 Other Locations Phone: (001)-714-632-7100 Fax: (001)-714-632-1044 9531-008-001-0X Rev.B...
-
Page 2: Table Des Matières
PROPERTY DAMAGE. KEEP THESE INSTALLATION INSTRUCTIONS IN AN EASILY ACCESSIBLE LOCATION FOR FUTURE REF- ERENCE. PREMIER MOUNTS DOES NOT WARRANT AGAINST DAMAGE CAUSED BY THE USE OF ANY PREMIER MOUNTS PRODUCT FOR PURPOSES OTHER THAN THOSE FOR WHICH IT WAS DESIGNED OR DAMAGE CAUSED BY UNAUTHORIZED... -
Page 3: Installation Tools
CONSERVER CES CONSIGNES D’INSTALLATION DANS UN ENDROIT FACILEMENT ACCESSIBLE POUR RÉFÉRENCE FUTURE. LES SUPPORTS PREMIER MOUNTS NE GARANTISSENT PAS CONTRE LES DOMMAGES CAUSÉS PAR L’USAGE DU PRODUIT DE MONTAGE PREMIER MOUNTS À D’AUTRES FINS QUE CELLES POUR LESQUELLES IL A ÉTÉ CONÇU OU DES DOMMAGES CAUSÉS PAR DES ACCESSOIRES OU DES MODIFICATIONS NON AUTORISÉS, ET NOUS NE POUVONS PAS ÊTRE TENUS RESPONSABLES DES DOMMAGES, PLAINTES, RÉCLAMATIONS,... -
Page 4: Parts List
Premier Mounts at (800) 368-9700. S’assurer que votre produit « Premier Mounts » a le matériel et les composants suivants avant de commencer l’installation. S’il y a des pièces manquantes et/ou endommagées, arrêter l’installation et appeler « Premier Mounts » au numéro (800) 368-9700. -
Page 5: Wood Stud Installation
AM175 Wood Stud Installation THE FOLLOWING STEPS MUST BE PERFORMED BY TWO PEOPLE. LES ÉTAPES SUIVANTES DOIVENT ÊTRE EXÉCUTÉES PAR DEUX PERSONNES. Minimum of 2 by 4 wood stud to be used Minimum de 2 par 4 bois goujon pour être utilisé... - Page 6 AM175 Step 10. Re-level the AM175. Mounting Slot Step 11. Using a 1/2” socket wrench, completely tighten the two (2) upper lag bolts. Flat Washer Do NOT over-tighten lag bolts when Upper Mounting Channel attaching the mount to the wall. Improper 5/16”...
-
Page 7: Concrete Surface Installation
AM175 Concrete Surface Installation THE FOLLOWING STEPS MUST BE PERFORMED BY TWO PEOPLE. LES ÉTAPES SUIVANTES DOIVENT ÊTRE EXÉCUTÉES PAR DEUX PERSONNES. If concrete wedge anchors are not used (as described in these installation instructions) and you decide on other mounting hardware, please follow the installation instructions as provided with that hardware. -
Page 8: Determining The Mounting Hardware
AM175 Step 7. Once all of the anchors are in place, move the wall bracket into position. Step 8. Attach the nut onto the threaded shaft that Level is protruding from the wall. Step 9. Re-level the wall plate and tighten all concrete wedge anchor nuts at this time. -
Page 9: Universal Spacer Installation
AM175 Universal Spacers Installation (optional) If your flat panel has uneven mounting points, or recessed mounting points, please use the provided universal spacers. Si votre écran plat comporte des points de montage inégaux, ou en- castrés, veuillez utiliser les entretoises universelles fournies. -
Page 10: Mounting Bracket Installation
AM175 Mounting Bracket Installation This kit provides a variety of screws with different lengths and diameters to accommodate most flat panels. The number and location of mounting points will vary between manufacturers. Le nombre et l’emplacement des joints de montage varient en fonction des fabricants. -
Page 11: Adapter Plate Installation (Optional)
If they are not aligned and level, the flat panel will not sit properly when mounted to the AM175. Avant de serrer l’écrou de nylon, s’assurer Adapter Plate que tous les deux supports de montage tous usages sont à... -
Page 12: Attaching The Flat Panel To The Wall
Flat Panel Step 1. Place the universal brackets and the flat panel over and onto the upper and lower mounting bars of the AM175 and lower it down. Do not release the flat panel until the flat panel is resting securely on the upper and lower mounting bars. -
Page 13: Adjusting The Flat Panel Tilt
AM175 Adjusting the Flat Panel Tilt TO ADJUST THE TILT TENSION OF THE AM175, LOOSEN THE TENSION BOLTS LOCATED ON THE BOTTOM RIGHT AND LEFT SIDE OF THE MAIN ARM ASSEMBLY. RE-TIGHTEN THESE BOLTS TO ACHIEVE YOUR DESIRED TENSION. POUR RÉGLER LA TENSION D’INCLINAISON AM175, DESSERRER LES BOULONS DE TENSION DANS LA PARTIE INFÉ- RIEURE DROITE ET DU CÔTÉ... -
Page 14: Technical Specifications
AM175 Technical Specification All measurements are in inches(mm). 34.31 33.21 3.21 16.00 25.71 26.43 14.02 Page 14 Installation Instructions... -
Page 15: Warranty
What Premier Mounts Will Do At the sole option of Premier Mounts, Premier Mounts will repair or replace any product or product part that is defective. If Premier Mounts chooses to replace a defective product or part, a replacement product or part will be shipped to you at no charge, but you must pay any labor costs.
