Important Safety Information
Read through this entire manual for important guidelines and instructions prior to assembly. Failure to follow these
guidelines and instructions can result in property damage or serious personal injuries.
This unit should be placed on a level surface. Failure to do so can result in poor product per-
formance or create a possible safety hazard. DO NOT CLIMB, STAND or USE THIS UNIT AS A
LADDER. TO PREVENT TIPPING, ALWAYS SECURE TO A WALL WITH SUITABLE FASTENERS, NOT
INCLUDED. DO NOT USE THIS UNIT TO STORE AQUARIUMS. CAUTION: CONTAINS SMALL PARTS,
KEEP CHILDREN AWAY DURING INSTALLATION. USE TWO OR MORE PEOPLE TO ASSEMBLE
AND MOVE THE UNIT TO AVOID INJURY. Do not use this unit for anything other than the
manufacturer's intended purpose. Use care when working with metal parts, wear gloves for
protection. Periodically inspect the unit to ensure brace/beam rivets are properly seated into
post slots. Keep this manual for future reference.
Do not exceed the maximum weight capacity of 1,000 lbs (453 kg) for each shelf, not to exceed
5,000 lbs (2,267 kg) for the entire shelving unit. Evenly distribute weight loads across entire
shelf surface. Always store larger, heavier items on the bottom levels and small lighter items
on the upper levels.
Warranty
Edsal Manufacturing Company, LLC products are guaranteed for a period of one (1) year from the date of purchase. The SOLE
AND EXCLUSIVE REMEDY for such defects is the repair or replacement of a defective product or parts thereof by Edsal Manufac-
turing Company, LLC or, at Edsal Manufacturing Company, LLC option, refund of the purchase price upon return of the item to
Edsal Manufacturing Company, LLC. This warranty shall not apply in the event the products are damaged as a result of misuse,
neglect, accident, moisture, improper application, improper assembly, or assembly not in conformity with the instructions of
Edsal Manufacturing Company, LLC, failure to abide by safety precautions prescribed by Edsal Manufacturing Company, LLC or
modification or repair by persons not authorized by Edsal Manufacturing Company, LLC.
Should you have any comments, damage, missing parts, or problems with
assembly of this unit contact us:
7 a.m. - 5 p.m., CST, Monday-Friday:
Chat: www.edsal.com/chat or www.edsal.com/contact
Email: support@edsal.com
Phone: 1-773-475-3131
To obtain replacement parts please provide: Model Number, Part Number & Description,
Store Location and Date Purc
THANK YOU FOR YOUR PURCHASE
5-SHELF STEEL STORAGE UNIT
hased
MODEL: MROP4824W5B
Item# 677589
EDSAL MANUFACTURING CO, LLC
CHICAGO, IL 60609
US Patents & Patents pending
rev: C101520_V1L
E
Publicité
Table des Matières
Sommaire des Matières pour Edsal Muscle Rack Pro Serie
- Page 1 Warranty Edsal Manufacturing Company, LLC products are guaranteed for a period of one (1) year from the date of purchase. The SOLE AND EXCLUSIVE REMEDY for such defects is the repair or replacement of a defective product or parts thereof by Edsal Manufac- turing Company, LLC or, at Edsal Manufacturing Company, LLC option, refund of the purchase price upon return of the item to Edsal Manufacturing Company, LLC.
-
Page 2: Preparation
Parts List Brace #TRBR24-BLK Wire Deck #2448W Beam #TRBM48-BLK Post Cap Support Hook Inside Post Connector #RL-PC-B1 #MR-WIRECLIP-10 #CPIN-BLK Post #URPS36-BLK Preparation Before beginning assembly, read though the instructions and make sure all parts are present. Assembly of this unit is done by fitting the two rivets of the braces (B) and beams (C) into the keyhole slots of the post (A). - Page 3 Assembly Assemble A (x4) and G (x4) ✓ ✓ Assemble B (x2) ✓ ✓ Assemble C (x2) ✓ ✓ Assemble D (x1) ✓...
- Page 4 Assembly Assemble E (x2) ✓ Inside View Inside View Inside View ✓ Insert Hook (E) into the Hook correctly engaged Attach the top of the Hook hole located in center of into the beam and on over the wire deck. Push beam’s bottom ledge.
- Page 5 Assembly Assemble A (x4) to the four assembled inside post connectors Note: A rubber mallet may be used to ✓ ✓ help secure the top posts into the post connectors by lightly tapping down on the post once it is attached to the post Inside View Outside View connector.
-
Page 6: Garantie
Garantie Les produits Edsal Manufacturing Company, LLC sont garantis pour une période d’un (1) an à compter de la date d’achat. Le SEUL ET EXCLUSIF RECOURS pour de tels défauts est la réparation ou le remplacement d’un produit ou de ses parties défectueuses par Edsal Manufacturing Company, LLC ou, selon le choix d’Edsal Manufacturing Company, LLC, le remboursement du prix d’achat à... -
Page 7: Liste Des Pièces Détachées
Liste des pièces détachées Entretoise N° TRBR24-BLK Treillis métallique N° 2448W Montant N° TRBM48-BLK Capuchon de Crochet de support Connecteur de poteau N° MR-WIRECLIP-10 poteau intérieur Poteau N° CPIN-BLK N° RL-PC-B1 N° URPS36-BLK Préparation Avant de commencer l’assemblage, lisez attentivement les instructions et assurez-vous que toutes les pièces sont présentes. L’assemblage de cette unité... -
Page 8: Assemblage
Assemblage Assemblez A (x4) et G (x4) ✓ ✓ Assemblez B (x2) ✓ ✓ Assemblez C (x2) ✓ ✓ Assemblez D (x1) ✓... - Page 9 Assemblage Assemblez C (x2) ✓ Vue intérieure Vue intérieure Vue intérieure ✓ Insérez le crochet (E) Crochet correctement Fixez le haut du crochet dans le trou situé au engagé dans le montant sur le support métallique. centre du rebord inférieur et sur le support Poussez légèrement le du montant.
- Page 10 Assemblage Assemblez A (x4) sur les quatre connecteurs de poteaux intérieurs Remarque : Un maillet en caoutchouc peut ✓ ✓ être utilisé pour aider à fixer les poteaux supérieurs dans les connecteurs de poteaux en tapant légèrement sur le poteau une Vue intérieure Vue extérieure fois fixé...
-
Page 11: Información De Seguridad Importante
Garantía Los productos de Edsal Manufacturing Company, LLC tienen garantía por un período de un (1) año a partir de la fecha de compra. LA ÚNICA SOLUCIÓN para un producto defectuoso es la reparación o el reemplazo del producto o de sus piezas por parte de Edsal Manufacturing Company, LLC o bien, a opción de Edsal Manufacturing Company, LLC, el reembolso del precio de compra una vez... -
Page 12: Lista De Piezas
Lista de piezas x 10 Larguero #TRBR24-BLK Estante de alambre #2448W x 10 Viga x 10 #TRBM48-BLK Tapa de poste Gancho de soporte Conector interior #RL-PC-B1 #MR-WIRECLIP-10 del poste Poste #CPIN-BLK #URPS36-BLK Preparación Antes de comenzar a ensamblar la unidad, lea todas las instrucciones y asegúrese de tener todas las piezas. El ensamblaje de esta unidad se realiza colocando los dos remaches de los largueros (B) y las vigas (C) en las ranuras de bocallave de cada poste (A). - Page 13 Ensamblaje Ensamble A (x 4) y G (x 4). ✓ ✓ Ensamble B (x 2). ✓ ✓ Ensamble C (x 2). ✓ ✓ Ensamble D (x 1). ✓...
- Page 14 Ensamblaje Ensamble E (x 2). ✓ Vista interior Vista interior Vista interior ✓ Pase el gancho (E) por el El gancho está conectado Pase la parte superior del orificio que se encuentra correctamente a la viga gancho por el estante de en el centro del borde y al estante de alambre.
- Page 15 Ensamblaje Ensamble la pieza A (x 4) en los cuatro conectores interiores del Nota: Puede utilizar un mazo de caucho ✓ ✓ poste, que ya están ensamblados. para fijar los postes superiores en los conectores del poste golpeando suavemente el poste una vez que esté Vista interior Vista exterior sujetado al conector del poste.
