Amity 3 is designed according to the latest designer trends distinguished by its simple, yet modern
straight lines which make it suitable for all kinds of spaces. The
colored in black temperature-resistant color which adds to its attractiveness.
A big glazed door makes the complete firebox visible which gives a complete sensation of open
fireplace. Its specific primary and secondary air supply allows the glass to remain completely clear
throughout the heating season. The stove boasts with high efficiency and the fire does not have to be
extinguished for days.
Please read the COMPLETE USER'S MANUAL in order to obtain the best possible results starting from
the very first use.
TECHNICAL DATA:
DIMENSIONS
W x H x D:
WEIGHT:
RATED OUTPUT:
EXECUTION TO EN 13 240:
FLUE CONNECTION – rear:
HEIGHT OF REAR FLUE CONN.
– FROM THE FLOOR:
INSTALLATION INSTRUCTIONS
Install the front plinth (162) as shown on the figure on the cover page. The chimney connection is
located on the rear side. The upper and the lower chimney installments, and chimney installments are
included in the package together with the stove itself. The ways of connecting the installments are shown on
Illustration 2. We recommend the use of installment as shown on illustration b)., figure 6, page 55. If you
should use the installment mode as shown on illustration a), please pay attention that the connection is
made with a slight elevation towards the chimney itself.
Figure 2
59,7x76,4x51,9 cm
128,5 kg
8
kW
1a
Ø120 mm
H=52 cm
16
stove is made of high-quality cast iron,
