Gatorback Mudflaps GCR29F Instructions De Montage page 5

INSTALLATION
(For ease of installation it is suggested that the wheel be removed)
FINISHING CAPS:
1. Remove the 4 factory screws from the existing factory guard. Set 2 of these factory screws aside for later
reinstallation. The remaining 2 can be discarded.
2. Use a 5/16" socket on an extension to collapse the push pin on the inside of the factory cap. You can reach the
push pin through the cavity of the fender (See video).
3. Slightly peel back the red 3M tape on the finishing cap and fold back so it can be fully peeled after cap is in place.
4. Position cap, ensuring the top lip of the cap slides under the fender molding as shown.
5. Reinstall the two factory screws on the underside of the finishing cap. Be careful not to overtighten.
6. Finish peeling 3M tape and press firmly on the bottom and side of the finishing cap to ensure a proper seal.
7. Repeat procedure on passenger side.
FACTORY CAP (GUARD)
REMOVE THE FOUR FACTORY SCREWS
(TWO ON FRONT & TWO UNDERNEATH)
Please check out our YouTube channel to see an install video for this application
FINISHING CAP (GUARD)
REINSTALL THE FOUR FACTORY SCREWS
TO THE FINISHING CAP (GUARD)
REINSTALL 2 FACTORY
SCREWS ON UNDERSIDE
OF FINISHING CAP
Sierra Rear
Sierra Rear
