INSTALATION - CONEXIONS
Before any connection, check that the inverter is turned OFF.
• Connect your 24V battery with the « DC INPUT » plugs on the back of your inverter, respecting the
polarities
(cables not provided):
Caution: Firmly tighten the clamps/ the terminals, otherwise there are risks of: no power, abnormal
overheating of the cable, and damages to the supply of the inverter or fire
• Connect your 12V battery with the « DC OUTPUT » terminals on the front of your inverter
respecting the polarities (cables not provided) :
•
- connect the black cable to the negative born of the battery (-),
- connect the red tong to the positive born of the battery (+).
Caution: Firmly tighten the clamps/ the terminals, otherwise there are risks of: no power, abnormal
overheating of the cable, and damages to the supply of the inverter or fire
•
Turn the Unipower ON. The led turns on as soon as the device is on.
• After using the inverter :
- turn the switch OFF
Caution: The metallic parts may be hot. Avoid to grasp it with the hands or to put it next to
inflammable products.
INTEGRATED PROTECTIONS
• The Unipower is equipped with thermal protection and electrical protection against overloads as well as
a low voltage and overvoltage protection.
The inverter turns off:
- when the inner temperature of the inverter is too high
- when the consumption of the connected devices is over the nominal power of the inverter
- when the battery voltage is to low or too high.
- when there is an output short-circuit.
