FEATURES

INCREASE THE DISTANCE

Increased terminal distance to each of the 4 outputs, up to 3 terminals on one output.

PROGRAMMING

Programming of home terminals: To select the programming mode we must configure the dipswitches

of the decoder. Make sure that the DL LED shows that the programming has been completed and

remains fixed.

Sequential mode:

With the decoder powered and the LED on, Press the PGM button for more than 1 second and less

than 10 seconds. When the button is released, the decoder starts, for each of the 4 outputs, the

terminal programming.

The address assigned to each of the outputs depends on the dipswitches configuration. See

ADDRESSES TABLE

Open mode:

free programming of terminals.

With the decoder powered up and the LED lit, set minidip number 8 of the "DECODER" dipswitch to

ON (Open mode), minidip 8 of the "BLOCK" dipswitch to ON.

There are two ways of programming an output:

- If the terminal has a programmed address already; by sending an F1 command, auto-on or Guard

unit call (key), the decoder will pick up the terminal address and store it in the output that has

received the command.

- If the terminal does not have an address, we can carry out the inverse programming with the panel.

Once we have finished the programming, put the dip 8 of the dipswitch BLOCK to OFF.

BLOCK THE INSTALLER MENU:

To avoid possible errors or misuse by the user, the access to the installer menu on the monitor can be

controlled by the decoder.

Sequential mode:

- To block the installer menu: After programming the decoder outputs, the installer menu will be

blocked.

- To unblock the installer menu: Press the programming button (PGM) on the decoder for 10

consecutive seconds to access the installer menu from the monitor (

minutes it will be locked again.

Open mode:

- To block the installer menu: Minidip 8 of dipswitch "BLOCK" to OFF.

- To unblock the installer menu: Minidip 8 of dipswitch "BLOCK" to ON.

ISOLATION BETWEEN TERMINALS

If a short circuit, voltage lower than 15 Vdc or over consumption (peak consumption greater than 1

A) is detected in any of the 4 outputs, this will be isolated from the rest and the system could reboot.

Every decoder output has 1 red LED, if it is on, it indicates that the output has a problem. We can

disconnect the output or turn off the decoder to recover it. If the short-circuit occurs in the cable without

having a terminal connected or there is a telephone connected, once the short-circuit is eliminated, the

output recovers automatically.
