("MAX" will be displayed above the indoor temperature and
humidity).
b. Press and release the "IN" key again to view the indoor mini-
mum temperature and humidity.
c. Press and release the "IN" key again to return to the normal
mode (timeout of viewing minimum/maximum values will occur
if no keys are pressed for fifteen seconds).
Note: To reset the indoor minimum and maximum temperature and
humidity, first display the values you wish to reset (minimum or
maximum). Next press and hold the "SET" key for at least three
seconds. You will see then that the values will reset to the current
temperature and humidity and corresponding time.
2. Outdoor Minimum and Maximum Temperature
The indoor weather station automatically stores the minimum and
maximum outdoor temperature. The minimum and maximum values
are updated automatically when a new minimum or maximum is
recorded, or until manually reset.
a. From the normal display mode, press and release the "OUT/+"
key once to view the outdoor maximum temperature ("MAX" will
be displayed above the outdoor temperature).
b. Press and release the "OUT/+" key again to view the outdoor
minimum temperature.
c. Press and release the "OUT/+" key again to return to the normal
mode (timeout of viewing minimum/maximum values will occur
if no keys are pressed for fifteen seconds).
Note: To reset the outdoor minimum and maximum temperature, first
display the values you wish to reset (minimum or maximum). Next
press and hold the "SET" key for at least three seconds. You will see
then that the values will reset to the current temperature and corre-
sponding time.
B. Multiple Remote Temperature Sensors
The WS-7394U is able to receive signals from 3 different remote
sensors. These extra remote sensors can be purchased through the
same dealer as this unit. A TX4U will monitor the temperature and
humidity, a TX3U will monitor temperature and display the tempera-
ture on its LCD, a TX3UP will monitor the temperature via a probe for
measuring soil or water temperatures and a TX6U will monitor the
temperature only.
GB
P.15
Note: When setting up multiple units it is important to insert batteries
first into all the remote sensors, and in numeric sequence. Second
install batteries into the indoor weather station. Transmission prob-
lems will arise if this is not done correctly and if the total time for set-up
exceeds 6 minutes
1. Set Up of Multiple Units
a. It is necessary to remove the batteries from all units currently in
operation.
b. Remove the battery covers to all remote sensors.
c. Place all remote sensors in a numeric sequential order.
d. In sequential order, install batteries following the same battery in-
stallation procedures seen in Detailed Set-Up Guide section of this
manual.
e. Install batteries into the indoor weather station.
f. Follow the Detailed Set-Up Guide for programming and operating
instructions.
2. Viewing and Operating with Multiple Remote Sensors
a. To view the temperature of a different remote sensor press and
release the "CH" button. A shift from one "boxed" number to the
next should be observed in the OUTDOOR LCD.
b. The minimum and maximum temperature of the additional remote
sensor can be displayed by pressing the "OUT/+" button.
c. To reset the minimum and maximum temperature readings press
and hold the "SET" button for 3 seconds and that temperature record
for that remote sensor will be reset only.
Each remote sensor will have its own minimum and maximum values
stored.
C. Comfort Indicator for Indoor Temperature and Humidity
1. The comfort level indicator appears inbetween the indoor
tempearture and humidity.
2. The indicator will display a "happy-face" when the temperature is
between 68˚F and 79˚F (20˚C and 25.9˚C), and the humidity is
between 45% and 64%.
3. A "sad-face" will be displayed when the temperature and humidity
are outside the mentioned ranges.
D. Weather Forecast Icon and Pressure Trend Indicators
The weather forecasting feature is estimated to be 75% accurate, and
is based solely upon the change of air pressure over time. The WS-
7394U averages past air-pressure readings to provide an accurate
