TECHNICAL SPECIFICATION

Age
Loading limit
Weight
Frame
Tyres
Rims
Deck
Brakes
Width of handle bars
Height of handle bars 70 / 77 cm
Lenght
Fulfills norm
Dear customer,
We would like to pass onto you our thanks for choosing this product. It is our duty to inform
you that this scooter in its basic version is intended for mild terrain and non-car traffi c
roads. It is possible that you will need to add more safety features, such as refl ectors, required
under the law of the country in which the scooter will be used. Also it is vital to use safety
features for the rider him/herself (see safety features section).
A very important aspect for the safe use of this product is the proper adjustment of the scooter
(wheel bearings, break inspection, bolt tightening, and proper tire infl ation). That is why we
highly recommend having the scooter assembled and regularly inspected by a professional
bicycle service, simply for the well informed skilled technicians who can assist you. By
securing yourself a properly set-up scooter with regular service you will be able to enjoy this
product for a long time to come.
Do not forget that our line of scooters is wide. You can choose from many diff erent sizes and
styles for diff erent age groups and uses (see back side or www.yedoo.eu).
If you have any ideas or comments please do not hesitate to contact us at our email address:
obchod@intrea.cz
ASSEMBLY INSTRUCTIONS
1. Control individual parts in the box:
(1 piece) main frame of scooter including front fork,
(1–2 pieces) brake system (depending on the type of scooter)
(2 pieces) infl atable wheels (according to the model: 2× 12'' , or 1× 16'' and 1× 12''),
(1 piece) handlebars including the handlebars rod.
Entrust a professional bicycle service with the assembly.
2. Unloose the nuts on the axis of both small wheels. If necessary, tighten the play of bearings so that
the wheels can turn freely (that is so that they do not drag and at the same time they are not free).
ONE TWO
4+ 5+
75 kg 100 kg
6,20 kg 7,40 kg
Hi-ten steel Hi-ten steel
12" 12"
Alu Alu
30 cm 32 cm
Foot brake 1× „V" alu
51 cm 53 cm
75 / 86 cm
108 cm 119 cm
ČSN EN 71-1+A9 ČSN EN 71-1+A9 ČSN EN 146 19 ČSN EN 146 19
THREE FOUR
8+ 12+
100 kg 120 kg
7,90 kg 9,30 kg
Hi-ten steel Hi-ten steel
12" 16" + 12"
Alu Alu
32 cm 36 cm
2× „V" alu 2× „V" alu
57 cm 66 cm
79 / 90 cm 93 / 104 cm
119 cm 135 cm
