CableMaster CM800/850
PORT TESTING
• Connect the CableMaster 800/850 to a switch or active network jack.
• From the Network/PoE screen, press the Port test soft key
• The CableMaster 800/850 will automatically perform a port test upon entering the Port Test
screen.
• Select one of the following Port Test soft keys to perform a specific test:
- DHCP – Obtain Network IP address and DHCP information
- LLDP – View Link Layer Discovery Protocol supported switch information
- CDP – View advertised Cisco protocol information
- Link Light –
connected to
HOW TO PERFORM A DEVICE DISCOVERY TEST
PING IPV4/IPV6
• Connect the CableMaster 800/850 to a switch, router, or active network jack.
• From the home screen, use the right arrow button to select the Network Discovery icon and
press the enter button
• The CableMaster 800/850 will perform a DHCP test and obtain an IP address (to ping IPV6, press
the IPV6 soft key).
• Press the ping soft key soft key
• Use the left and right arrows to highlight a digit. To change a digit, use the up and down arrows
or press the keypad soft key soft key
press the keypad soft key again.
• Press the test button to ping the IP address.
LIST
• Press the list soft key
addresses
• To ping an IP address in the list, use the up and down buttons to navigate to the desired IP
address and press the test button.
FAVORITES
• From the List screen, press the Favorites soft key soft key
• Use the up and down arrow buttons to scroll through the list.
• Press the test button
URL IP address obtained by the DNS server.
• Press the test button
IP DISCOVERY
• From the Network Discovery screen, press the IP discovery soft key. soft key.
• The CableMaster 800/850 will scan the network and display IP addresses within a Network. The
list will include device labels to the left of the IP addresses.
• Use the up and down arrow buttons to scroll through the IP list. Press the enter
view the MAC address associated with the selected IP address.
TCP/UDP THROUGHPUT TESTING
• Please refer to the CableMaster 800/850 instruction manual for TCP/UDP throughput Innovation
4 4
Flash the port LED on a hub, switch, or router to identify the port you are
or press the Network Discovery soft key soft key
.
to use an alphanumeric keypad. To unselect the keypad,
soft key to view discovered IP addresses and manually pinged IP
to select an IP or URL address. The CableMaster 800/850 will show the
again to ping the IP address.
.
.
to ping from the favorites list.
button to
