FRONT I/O BUTTONS and PORTS
USB 3.0 x2
Hybrid Audio Port
FRONT I/O CABLES
Please consult your user manual of motherboard manufacturer,
then connect these leads to the panel header on the motherboard.
USB 3.0 Connection : Please refer to the motherboard manual
for more information on the USB 3.0 connection.
Audio Connection：Please refer to the motherboard installation to
avoid the device error and cause the motherboard sound device to
be damaged.
PRE-SET LIGHTING EFFECTS
MODE DESCRIPTIONS
Mode 1
Mode 2
Red
Green
Mode 6
Mode 7
White
Orange
Neon Green
LED Button
Powen Button
Mode 3
Mode 4
Mode 5
Blue
Purple
Yellow
Mode 8
Mode 9-12
Mode 13
Lighting effect
Off
No. 1-4
05
DIMENSIONS and COMPATIBILITY
Mini-ITX
Micro-ATX
ATX
E-ATX
441mm
VGA Length Limitation
CPU Cooler Height Limitation
PSU Length Limitation
220mm
380mm
170mm
220mm
