NOTICE TECHNIQUE CY 236 MP – 336 MP – 436 MP/E – 536 MP/E
La partie maintenance est destinée aux dépanneurs et personnes habilitées.
Maintenance = pièces de rechange préconisées pour N1 : parc de 1 poste, N2 : parc de 10 postes.
Rép. Qté
Réf. CY
CY 236
MP
1
2
40.029.103 40.029.103 40.029.103 40.029.103 Anneau de levage
2
2
40.748.025 40.748.025 40.748.025 40.748.025 Poignée noires Lg 300
3
1
40.602.004 40.602.004 40.602.004 40.602.004 Loquet ¼ Tour
4
1
40.015.012 40.015.012 40.015.012
5
2
40.124.023 40.124.023 40.124.023 40.124.023 Calotte de roue
6
2
40.869.021 40.869.020 40.869.020 40.869.020 Roue
7
2
40.869.022 40.869.010 40.869.010 40.869.010 Roulette pivotante
8
1
40.016.003 40.016.003 40.016.003 40.016.003 Afficheur LCD
9
1
40.124.900 40.124.900 40.124.900 40.124.900 CI. commutateur
10
1
40.124.888 40.124.888 40.124.888 40.124.888 CI. potentiomètre
11
2
40.558.019 40.558.019 40.558.019 40.558.019 Inverseur 2 positions
12
1
40.140.125 40.140.125 40.140.125 40.140.125 Commutateur 0/1
13
1
40.175.028 40.175.028 40.175.028 40.175.028 Connecteur 7 broches
14
2
40.222.053 40.222.053 40.222.076 40.222.076 Embase femelle ¼ de tour
15
1
40.124.876 40.124.966 40.124.965 40.124.138 CI. de commande
16
1
40.940.047 40.940.047 40.940.047 40.940.047 Transfo auxiliaire
17
1
40.442.009 40.442.009 40.442.009 40.442.009 Electrovanne
18
1
40.938.308 40.938.308 40.938.308 40.938.308 Tore
40.938.304 40.938.304 40.938.304 40.938.304 Tore
19
1
40.796.012 40.796.012 40.796.012 40.796.012 Relais 48V ALT
20
1
40.697.002 40.697.002 40.697.002 40.697.002 PAB 10A
21
1
40.697.013 40.697.013 40.697.013 40.697.013 PAB 3 plots
22
1
40.124.928 40.124.928 40.124.928 40.124.928 Circuit CEM
23
1
40.909.013 40.909.013 40.909.013 40.909.013 Thermostat 40°
24
1
40.886.041 40.886.041 40.886.041 40.886.041 Shunt
25
1
40.909.012 40.909.012 40.909.012 40.909.012 Thermostat 90°
26
1
40.455.994 40.455.995 40.455.996 40.455.965 Redresseur
40.800.007 40.800.007 40.800.007 40.800.007 Résistance 56 Ω 280 W
27
1
28
1
40.869.023
29
1
40.504.017 40.504.017 40.504.017 40.504.017 Fusible (F2) 3,15 A
30
1
40.504.007 40.504.007 40.504.007 40.504.007 Fusible (F3) 800 mA
31
1
40.504.007 40.504.007 40.504.007 40.504.007 Fusible (F4) 800 mA
31
1
40.504.005 40.504.005 40.504.005 40.504.005 Fusible (F5) 100 mA
32
1
40.558.019 40.558.019 40.558.019 40.558.019 Inverseur Bipol
33
1
40.904.031 40.904.031 40.904.031
APPAREILS SEMI-AUTOMATIQUES
MAINTENANCE
SCHEMAS ET NOMENCLATURES
Réf. CY
Réf. CY
CY 336
CY 436
MP
MP/E
Réf. CY
CY 536
MP/E
Adaptateur torche
Roulette fixe ∅ 23
Support bobine
NOTICE N° 40 636 185
DATE CREATION : 05/96
DATE MISE A JOUR : 09/97
Désignation
Page 5
N1 N2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
