OPERATION
Improperly attached hoses or accessories can become detached under pressure
WARNING:
and causeserious injury. Possible air leaks can cause faulty pressure readings.
Make sure all connections are tightly secured.
5. If self-locking swtich is up, turn it down .
6. Press "ON/Unit" button to read the current tire pressure on the gauge. Press "ON/Unit" button
again to select tire pressure measurement unit from PSI, KPA, BAR, KG/CM.
7. Press "+" or "-" button to adjust preset tire pressure.
(1) Long press "+" or "-" button to adjust working pressure quickly.
(2) Press "+" or "-" button each time can adjust preset working pressure by 0.05BAR &KG/CM, 1.0
PSI, 5KPA.
8. Preset pressure value will be set after flashing for 3 seconds.
Press switch to start inflating. When it reaches the preset pressure value, the device will stop
working.
NOTE: To reset the tire pressure measurement unit, press "ON/Unit" to reselect after setting
preset pressure value.
NOTE: Digital gauge records the preset measurement unit and value of last time operation
NOTE: After the air pump reaches the preset pressure value, the digital gauge will go off after
30 seconds, and the device will shut down automatically.
NOTE: Maximum PSI for this unit is 100PSI.
A- Air chuck clamp in
unlocked position
Fig.1
Always leave the hose free of obstructions when the tool is not in use. Overheating
NOTICE:
could occur if the hose is blocked.

ACCESSORIES

The supplied accessories perform a variety of functions. The tapered adaptor can be used on
smaller pinch valves to inflate small items like children's toys, which usually require the user to
inflate them by blowing air into them. The sport ball needle can be used to inflate any type of
sports ball or any other item that requires an inflation sport ball needle.
NOTE: When inflating items of 10 PSI or less, inflate in short bursts and check after each burst
by feel or with a calibrated measuring device to determine accurate pressure.
SPORT BALL NEEDLE:
1. Insert sport ball needle into sports ball valve and inflate.
2. Remove sport ball needle after inflation.
NOTE: Pressure required for most sports balls is too low for accurate reading on tool gauge.
8
B - Air chuck clamp in
locked position
F
E D
C
C - Valve stem
D - Air chuck
E -Air hose
F - Air chuck clamp
!
