System Map: Front View with Display Open

Figure 2 - Front View with Display Open
1. Webcam
2. *Camera LED
*When the camera is in use, the LED will
be illuminated.
3. Built-In Array Microphone
3 1 3
2
4
Model A
15.6" (39.62cm)
5
6
7
4. Display
5. Power Button
6. Keyboard
7. Touchpad & Buttons
3 1 3
2
4
Model B
17.3" (43.94cm)
5
6
7
7
Note that the Touchpad and Buttons
valid operational area is that indicated
within the dotted lines above.
5
