Brocade DCX 8510-8, nonport side

The following figure shows a sample configuration of the nonport side view of the Brocade DCX 8510-8.
1 WWN bezel (logo plate - WWN card behind with serial
number on the card)
2 Power supply
FIGURE 2
Nonport side of the Brocade DCX 8510-8 (sample configuration)

Time and items required for installation

You can set up and install the Brocade DCX 8510-8 in the following ways:
•
As a standalone unit on a flat surface.
•
In a 19-inch Electronic Industries Association (EIA) cabinet, using the 14U Rack Mount Kit (provided).
6 of 292
3 Blower assembly
Brocade DCX 8510-8 Backbone QuickStart Guide
