Operating Instructions
MaxLite CCT Selectable Vapor Proof Jelly Jar
®
Installation Instructions
Installation type 2:
STEP 1
First the wire is threaded through
the round hole in the base
When installed on the outdoor side wall,
the inside bend pipe of this part can prevent
water flow in from the wall seam
STEP 4
Connect the wires
GND
N
L
© Copyright 2021. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: 800-555-5629 Fax: 973-244-7333 Email: info@maxlite.com
STEP 2
Tighten the bottom hole mounting
and aim it with the upper hole
Screw the base
STEP 5
Add the Stainless steel followed by the
Silicone washers to the PM5*13 screws
Tighten the screws
then tighten the screws.
STEP 3
Move the gasket to access the CCT switch
and select desired CCT
JJ Series
3000K
4000K
5000K
Page: 4
REV: 4/12/21
