2 Description of the TV

2.1 Front

LED: Status Indicator, Red = Standby, Green = Power
IR sensor: remote control receiving sensor
Warning! The position of the LED and IR sensor may not correspond exactly to the one
shown in the picture.

2.2 Keyboard

The TV keyboard controls is on the right side of TV itself. The available keys are (from
left to right):
Vol+:
increase volume
Vol-:
decreases the volume
CH+:
change to the next channel
CH-:
change to the previous channel
Menu:
access the main menu
Source:
select source
Power:
Standby mode (OFF/ON)

2.3 Rear panel connections

On the back side of the TV, there are connections and A/V inputs.
Common Interface slot (compatibile with CI+ module)
USB port (Media Player Function)
HDMI
Coaxial digital audio output (COAXIAL)
SATELLITE RF Antenna Input (Type F)
TERRESTRIAL Antenna RF input (IEC)
PC Audio input (PC Audio IN)
RCA Video + Audio input
VGA port (PC)
Headphone output (3.5 mm jack)
12V DC power supply
