GB
S.A.S. au capital de 5 000 000 ! - Z.I. Les Giranaux - BP71 - 70103 Arc-Les-Gray CEDEX - RCS GRAY B 425 650 090 - SIRET 425 650 090 00011 - n° T.V.A CEE FR 87 425 650 090
Hereby SIMU declare that this equipment "Hz dry contact transmitter" is in compliance with the essential requirements and other relevant provisions
of directive 1999/5/EC. A declaration of conformity is available at the web adress : www.simu.fr. Usable in UE, CH.
1
Technical data
80
45
80
- Power supply: 230V-50Hz
- P : 1,3W
- Radio frequency: 433.42MHz
- Ambient temperature of use: 5T40 (+5°C à +40°C)
- Protection Index: IP 30 (indoor use only)
- Transmitter range throught 2 concrete walls: 20 m in normal pollution condition.
2
Installation
1
Ø65
2
m
6 0 m
Flush monting
3
Wiring
control switch
230V/ 50Hz
L
N PE
5 4 3
2
1
C
N
L
4
Programming the transmitter with an existing installation
Procedure for programming a new transmitter :
4.1 - Open the memory of the receiver using its individual control transmitter :
or
or
0:00
w
COS 1
PROG
PROG
4.2 - Then validate the operation from the Dry Contact Transmitter:
Press the PROG key of the new transmitter for one second. The motor will run for about half a second in one direction, then in the other.
PROG
For group controls from the dry contact transmitter, repeat operations 4.1 and 4.2 for each receiver of the group.
For main controls from the dry contact transmitter, repeat operations 4.1 and 4.2 for each receiver of the installation.
To delete this transmitter from the memory of a receiver, perform operation 4.1 with a programmed transmitter, then perform operation 4.2 with the dry contact transmitter.
For more complete information about programming, please refer to the instructions of the receiver used.
5
Functionning details
The chart beside indicates the function of the Hz dry
Hz DRY CONTACT TRANSMITTER - 2006020
PROGRAMMING LED
3
4
5
BLUE
BROWN
BLACK
RED
GREEN / TELLOW
or
PROG
PROG
ORDERS
contact transmitter:
STOP
Used with an unstable key switch or a double push button
switch, the dry contact Hz transmitter allow to control
PROGRAMMING KEY
one or several receiver(s) of the SIMU Hz range.
- Weight: 0,145 kg
- Transmission timing min: 0,5 sec., max 10sec.
- The Hz dry contact transmitter is compatible with Hz receiver and Hz.02, DMI
Hz.01, EHz, ESP Hz, AutoShort Hz motors.
- A radio appliance using the same frequency (for example: hi-fi radio headphones)
may deteriorate our product's performance.
2
1
9154122
3
Surface mounting
EXAMPLE OF WIRING WITH THE SIMU UNIVERSAL KEY BOX (2004964)
5 4 3
Press the PROG. Key for about 3 sec. on the receiver's individual control transmitter,
the motor rotates by about 1/2 sec. in one direction, then in the other.
ACTION
Close the contact between C and
Close the contact between C and
Close both contacts simultaneously
5014711B
Read carefully these instructions
before any use.
Do not position the transmitter
4
near metal in order to ensure its
5
good working (range losses).
230Vac / 50Hz
L
N PE
2
1
C
N
L
FUNCTIONNING MODE
Used with a key switch, this transmitter
does not allow the "STOP" order!
POSITION OF THE RED / GREEN PINS
UNSTABLE WAY
AND WAY
WAY
WAY
1/1
