Manuels Connexes pour Laney AUDIOHUB AH40
Sommaire des Matières pour Laney AUDIOHUB AH40
- Page 2 WARNING: When using electrical products, basic cautions should always be followed, including the following: 1. Read these instructions. 2. Keep these instructions safe. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7.
- Page 3 ATTENTION: L’utilisation de tout appareil électrique doit être soumise aux precautions d’usage incluant: 1. Lire ces instructions 2. Gardez ce manuel pour de futures références. 3. Prétez attention aux messages de précautions de ce manuel. 4. Suivez ces instructions. 5. N’utilisez pas cette unité proche de plans d’eau. 6.
- Page 4 ACHTUNG: Beim Einsatz von Elektrogeräten müssen u.a. grundlegende Vorsichtsmaßnahmen befolgt werden: 1. Lesen Sie sich diese Anweisungen durch. 2. Bewahren Sie diese Anweisungen auf. 3. Beachten Sie alle Warnungen. 4. Befolgen Sie alle Anweisungen. 5. Setzen Sie dieses Gerät nicht in der Nähe von Wasser ein. 6.
- Page 5 CUIDADO: Cuando use productos electrónicos, debe tomar precauciones básicas, incluyendo las siguientes: 1. Lea estas instrucciones. 2. Guarde estas instrucciones. 3. Haga caso de todos los consejos. 4. Siga todas las instrucciones. 5. No usar este aparato cerca del agua. 6.
- Page 6 For a description of the function of each control feature, simply check the number with the explanations adjacent to each panel. Your Laney amplifier has undergone a thorough two stage, pre- delivery inspection, involving actual play testing. When you first receive your Laney amplifier, follow these simple...
- Page 7 SPECIFICATIONS AH40 AH80 ~115V, ~220V/~230V 50/60Hz Supply Voltage on all models: Mains Fuse: ~115V T1A L T3.15A L ~220V/~230V T500mA L T1.6A L Output Power Rating Inputs 1 x Balanced Mic(XLR)/Unbalanced Line(Jack) 1 x Stereo Unbalanced Line (2 x Jack) 1 x Line/Hi-Z Instrument (Jack) Aux In (3.5mm Jack) Global 5 Band Graphic Equaliser (±12dB)
- Page 9 INTRODUCTION The Audiohub range of multi instrument amplifiers is designed to be the centre of your audio world. The portable AH40 and AH80 amplifiers each feature 3 independent channels allowing connection of balanced XLR, line and Hi- Impedance/Instruments, as well as a dedicated Aux In. The AH40 and AH80 are driven by 40W and 80W output sections respectively.
- Page 10 AH40 FRONT PANEL 1. CH1 MIC INPUT Balanced XLR input for low impedance microphone signals (200-600 Ohms). 2. CH1 LINE INPUT Unbalanced Jack input socket for connection of all line level signals (keyboard, signal processor, sample, drum machine, etc.). Note that the Mic and Line inputs may be used simultaneously, although it may be difficult to balance input levels, depending on your source. 3.
- Page 11 AH80 FRONT PANEL 1. CH1 MIC INPUT Balanced XLR input for low impedance microphone signals (200-600 Ohms). 2. CH1 LINE INPUT Unbalanced Jack input socket for connection of all line level signals (keyboard, signal processor, sample, drum machine, etc.). Note that the Mic and Line inputs may be used simultaneously, although it may be difficult to balance input levels, depending on your source.
- Page 12 AH40/AH80 REAR PANEL (AH80 SHOWN. AH40 SIMILAR) 18. VOLTAGE SELECT SWITCH This is factory set to the correct voltage for the region the product is supplied to. If necessary it can be reset by removing the mains lead and then loosening (but not removing) the screws securing the cover. The cover can then be pivoted away from the switch which can be moved to select the alternate voltage.
-
Page 13: Block Diagram
BLOCK DIAGRAM Pre Out 5 Band EQ Level Headphones Line Master Volume AH80 ONLY Aux In (3.5mm) Power amp Internal Speakers Line (L) Level Limiter Line (R) AH80 ONLY AH80 ONLY Instrument (Hi-Z)/Line Level Delay Feedback INTERNAL FX Level AH80 ONLY... - Page 14 SAMPLE SETUP RECORD OUT KEYBOARD BASS...
- Page 15 NOTES...
