Connect the Power Supply Cable to the rangehood. Attach the White lead of
4
the power supply to the White lead of the rangehood with a twist-on type wire
connector. Attach the Black lead of the power supply to the Black lead of the
rangehood with a twist-on type wire connector. Connect the Green (Green and
Yellow) ground wire under the Free Green grounding screw.
Green Grounding Screw
Close the Power Supply box with 2 screws (H).
5
6
Grounding Bracket
Grounding Bracket
Green Grounding Screw
H
