PRELIMINARY OPERATIONS

Recommendation:
For personnel and product safety
please read the contents of these
operating instructions carefully before
connecting.

GENERAL INFORMATION

10
All manuals and user guides at all-guides.com
Check the following points as soon as
you receive the Countis ATd package:
• the packing is in good condition,
• the product has not been damaged
during transit,

FUNCTIONS

The Countis ATd is an active energy
meter with 80A direct input. This pro-
duct enables direct readings of total
or partial consumption via LCD dis-
PRESENTATION
The Countis ATd is housed in a
modular case (7 versions).
The display and key-pad make it a
truly user-friendly instrument.
1
2
3
kWh consumption display
1
2 Flashing icon indicating incorrect
connection
3 Total and partial display, or
scrolling in programming mode
• the product reference number con-
forms to your order,
• the package contains the product
fitted with 2 terminal shrouds,
• operating instructions.
play, and is thus fully compliant with
standard IEC 61036 Class 2. It is enti-
rely programmable and has a fixed
100Wh pulse output.
126
4
Confirm programming
4
5 Consumption indicator
(10Wh/pulse)
SOCOMEC - Réf. : 875 452A
5
